UAF offers diverse solutions to meet changing HVAC standards.

Designed for a wide range of self-contained heating and air conditioning units, UAF aftermarket replacement air filters are custom made to meet your precise PTAC requirements.

Applications

PTAC units are popular in hotels, office buildings, condominiums, apartment buildings and even those hard to reach spaces in residential homes!

Frame

Windowpane style frames maintain necessary rigidity, keeping their shape and staying in place with an innovative “frame-n-pane” design that integrates the frame and a series of reinforcing intermediates that provide media support. Pane sizes and frame thickness are customized to the equipment’s needs

Media

Unifoam is an open cell polyurethane foam which meets UL900 specially formulated to meet a UL 94 HF-1 flame safety rating.  The random arrangement of strands and pores make this a filter media have tremendous dust-holding capacity and arrestance.

Quadrafoam and Quadrafoam II are open cell polyurethane foam. Quadrafoam and Quadrafoam II feature deep loading, high dust holding capacity and low air flow resistance for use in extremely wide climatic conditions.

Metal Mesh screens of aluminum and stainless steel may also be specified for long-lasting durability in harsh environments and applications requiring extremely thin, low profile frames

Tolerances

Roll-Formed Channel +/- 0.06″ length & width, +/- 0.03″ thickness.

WIndowpane: +/- 0.03″ length, width, and thickness

---

UAF supports full compliance with stringent industry standards:

---

UAF Filtration Products for Room Unit Filters

---
